The Ace wall panel is a prefabricated panel system that is environmentally friendly product with a pre-finished surface face with a hollow core centre made from gypsum plaster with glass re-enforced fibres and waterproofing polymer.
The Ace wall panels are manufactured in custom pack lengths up to 3.6m.
The Ace wall panel reduces the la
The Ace wall panel is a prefabricated panel system that is environmentally friendly product with a pre-finished surface face with a hollow core centre made from gypsum plaster with glass re-enforced fibres and waterproofing polymer.
The Ace wall panels are manufactured in custom pack lengths up to 3.6m.
The Ace wall panel reduces the labour costs on site due to the prefabricated nature of the product therefore saving on the construction program and the overall cost on the project.
Our Products
Our Products
Our Products
Ace-Wall™ is a fibre-reinforced, water-resistant, gypsum-based, non-load-bearing wall panel, designed for external and internal applications within modern residential, commercial and industrial low-rise and high-rise developments. The product is set to revolutionize the construction industry due to its low product and installation cost, r
Ace-Wall™ is a fibre-reinforced, water-resistant, gypsum-based, non-load-bearing wall panel, designed for external and internal applications within modern residential, commercial and industrial low-rise and high-rise developments. The product is set to revolutionize the construction industry due to its low product and installation cost, rapid installation, high strength-to-weight ratio, advanced sound/thermal/fire performance and strong eco-friendly characteristics.
The product is a full height wall panel with a standard width of 60 cm, a wall thickness of 10 cm and a specified height of between 2.1 m and 3.6 m.
The moulded panel is produced with “tongue and groove” joining surfaces and internal cavities to reduce weight and serve as internal conduits for the installation of electrical wiring and other services.
The moulded panel is produced to tight dimensional tolerances and has smooth external surfaces which do not require any on-site treatment or rendering.
Applications
- Internal partitions including fire rated and acoustic walls
- Internal Party walls and corridor walls, fire rated or non-fire rated
- External walls replacing cladding and non-load bearing brickwork allowing for a painted or rendered finish
- External boundary walls and boundary fencing
- Fire rated riser shafts
- Factory separation walls
- Plant room walls
- Office partitions
Installation Process
- Ace Wall systems can be installed by a suitable skilled person with minimal tools and equipment.
- Removes the need for wet trade such as bricklayers or concreters and rendering trades.
- Reduced weight on the structure allowing for minimal slab thickness and beam design.
- High volume of panels can be installed due to the prefabricated nature of the panels with a limited labour force.
Commercial Applications and Projects
- Ace wall systems can be supplied directly to the builder/contractor or the end user with onsite training provided by the manufacturer.
- The auxiliary products and components as part of the tested system such as the base track, head track, flashing, angles, along with fixings and sealants can be supplied with the panels.
- Routine inspections on the installation of the Ace wall panel system ensuring the system are installed as per manufacturers recommendations.
- Premanufactured panel lengths in packs of 11 based on high volume installations on site.
- Reducing building program with quicker installation in comparison to other prefabricated systems in the market.
- Can be finished with a smooth paintable class 5 finish.
- The panels are easily repaired if they are damaged.
- Services can be installed in the cavity of the wall.
- Removes the requirement for internal framework to support the lining material.
Installation
Our Products
Installation
for more information installation guides technical information email support@cnzinsulation.co.nz
